The newest single pass printer by Innovative Digital Systems.

SonicJet SP100 was designed to efficiently print on a wide range of products in a single pass, utilizing full process color print capabilities, UV/LED cure technology, and integrated inline plasma pretreatment, all provided standard. The SonicJet can be configured with spot colors, process colors, primers, and varnish clearcoats offering flexibility to suit your specific color and print durability needs.

  • Fast Throughput
  • Efficient Single Pass Printing
  • Ideal for Single or Multi-Color Printing
  • Wide Color Gamut
Download Brochure

Unlock the most efficient and cost-effective method for producing high-quality digitally printed objects.

Maximize productivity and reduce costs while achieving exceptional print results with the Sonic Jet SP100.

Vibrant Color Richness

Sharp, Precise Text Definition

Barcoding Capability

Single or Multi-Color Printing

SonicJet SP100 Specs

Max Full Color Resolution

600dpi per color

Max Print Width

100mm
(up to 200mm by special order)

Print Speed

79 ft/min

Features

Single pass full-color capability

UV/LED Curing

Integrated inline plasma pre-treatment

Next Part Detection

Barcoding Capability

Vacuum-assisted to keep objects in place

Download Brochure

Send Profits Skyrocketing With The SonicJet SP100

  • This field is for validation purposes and should be left unchanged.

Interested in the SonicJet SP100?
Let's Talk

Looking to elevate your printing capabilities? The Sonic Jet SP100 is a high-performance, single-pass UV LED flatbed printer designed for precision and speed. Perfect for a variety of materials, it delivers exceptional quality with minimal waste. Fill out the form below to inquire about purchasing the Sonic Jet SP100 and transform your production process today!

SonicJet SP100 Spec Sheet

SonicJet SP100 Single Pass Printer Specifications

Print SystemDOD piezo electric grayscale Ricoh Gen 4 print heads, automatic voltage & temperature control
Max Resolution600 DPI Full Color (P+W+CMYK+V)
1200 DPI Monochrome or Spot Color
InkUV-LED curable + KMYC + W + remirPVarnish (clearcoat). All inks are Prop65 compliant.
Print Speed79 feet (24 meters) per minute
Colors8 color bases (reconfiguration for jettable primer, varnish or expanded color gamut inks is available)
Maximum Print SizeMax width: 100mm (up to 200mm by special order)
Max Length: No Limitations
Media
Thickness5.91 in
Weight13.23 lbs.
Height AdjustmentAutomatic
Interface/RIP SoftwareGigabit Ethernet, ColorPRINT Bottle RIP, PCS 6
Power requirements220V± 10%(50/60Hz) ; 7.5 Amps Maximum; 1650 W Power Maximum
Operational environmentTemperature61°- 82 F (16°- 28° C)
HumidityOperating: 40% – 70%
AltitudeUp to 1000m (3,281′)
WeightTBD
Dimensions (W x D x H)3050mm x 1500mm x 1660mm
